iPECS UCP600 - Alphanumeric Data Entries; Appendix D: Station Admin Programming for Emg; General; LCD & Button Functions

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
72
4 Appendix D: Station Admin Programming for eMG
4.1 General
4.1.1 LCD & Button Functions
While in the Program mode, the Liquid Crystal Display (LCD) and Flex button LEDs of an Admin Station are
used to guide and indicate the status of the feature. The dial-pad is most often used to enter data after
selecting a data item using the Flex buttons. In some cases, pressing a Flex button will toggle the entry with
the Flex button LED indicating the status (On/Off).
For Programs with multiple Flex button selections, the volume controls ([VOL UP] and [VOL DOWN] buttons)
may be used to select the next or previous item. The [SPEED] button is generally employed as a delete button
to erase existing entries. However, where noted, it may be used to confirm a range input. Pressing the [CONF]
button returns to the 1st step of the data entry procedure for the Program without storing unsaved entries.
The [Save]button is used to store data after entry. If there are no conflicts in the entered data, a confirmation
tone will be received and the data stored. If a conflict exists, an error tone is provided, and newly entered data
are not saved. Generally, corrected data may be entered and stored without restarting the entry procedure
from the 1st step.
4.1.2 Alphanumeric Data Entries
In some cases, an alphanumeric entry is required. Two (2) dial-pad digits represent each character of an
alphanumeric entry, as shown in Table 3.1.2–1 below. Use the Table to determine the two digits that must be
entered from the dial-pad for each character.
Table 3.1.2-1 ALPHANUMERIC DIAL-PAD ENTRIES
1
Q – 11
Z – 12
. – 13
1 – 10
2
A - 21
B - 22
C - 23
2 - 20
3
D - 31
E - 32
F - 33
3 - 30
4
G – 41
H - 42
I - 43
4 - 40
5
J - 51
K - 52
L - 53
5 - 50
6
M - 61
N - 62
O - 63
6 - 60
7
P - 71
R - 72
S - 73
Q - 7*
7 - 70
8
T - 81
U - 82
V - 83
8 - 80
9
W - 91
X - 92
Y - 93
Z - 9#
9 - 90
*
Blank - *1
: - *2
, - *3
0
0-00
#
#
