4.3.15 PRINT-OUT DATABASE — PGM 451
The system can output all or portions of the system database to provide a ‘hard-copy. The data is output over
the appropriate Serial port (Serial 1 or Serial 2).
PROCEDURE:
DATABASE PRINT OUT
PRESS FLEX KEY (01-22)
Press the [PGM] button and dial 451.
Select Flex button 1~22 to output the desired data. Refer to Table 3.3.15-1.
For Station, Station Flex buttons, and CO/IP line data, use the dial pad to
enter the desired range for stations or CO/IP lines, or for all, skip this step.
Press the [Save] button. After output, a confirmation tone is heard.
Table 3.3.15-1 DATABASE PRINT OUT (PGM 451)
BTN
DISPLAY
REMARK
1
DATABASE PRINT OUT
FLEX NUM PLAN
2
DATABASE PRINT OUT
IP SETTING PLAN
3
DATABASE PRINT OUT
STA DATA(ENT STA RNG)
A station range must be entered to output the Station data.
4
DATABASE PRINT OUT
COL DATA(ENT COL RNG)
A CO/IP line range (01~21) must be entered to output CO/IP
data.
5
DATABASE PRINT OUT
SYSTEM DATA
6
DATABASE PRINT OUT
STATION GROUP
7
DATABASE PRINT OUT
ISDN TABLES
8
DATABASE PRINT OUT
SYSTEM TIMER
9
DATABASE PRINT OUT
TOLL TABLES
10
DATABASE PRINT OUT
LCR DATA
