iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
176
Table 4.4.5.18-1 LED INDICATION
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
Timed Ring mode
DND led of attendant station for ring
mode.
00-14
FLASH 240
IPM(5)
Auto Ring mode
DND led of attendant station for ring
mode.
00-14
FLASH 480
IPM(8)
Page Hold Button
HOLD LED for paging.
00-14
FLASH 60
IPM(3)
DSS Station DND(off
duty)
DSS button station in Station DND.
00-14
FLASH 120
IPM(10)
Message Wait (Call
Back)
Message wait.
00-14
FLASH 30
IPM(2)
DSS in use
DSS button station is in use.
00-14
Steady On
(1)
Table 4.4.5.18-2 LED FLASH RATE TABLE
Flash Rate
DESCRIPTION
1
Steady On
2
30 ipm flash (30% On)
3
60 ipm flash (30% On)
4
60 ipm double wink (30% On-Off-On-Off & 70% On)
5
240 ipm flash (30% On)
6
240 ipm flutter (30% On-Off-On-Off-On & 70% Off)
7
480 ipm flash (30% On)
8
480 ipm flutter (30% On-Off-On-Off-On & 70% Off)
9
15 ipm flash (30% On)
10
120 ipm flash (30% On)
11
120 ipm flutter (30% On-Off-On-Off-On & 70% Off)
12
30 ipm double flash (30% On-Off-On & 70% Off)
13
480 ipm double wink (30% On-Off-On-Off & 70% On)
14
480 ipm double flash (30% On-Off-On & 70% Off)
