iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
327
Table 4.4.10.6-1 NETWORK NUMBERING PLAN TABLE
ATTRIBUTE
DESCRIPTION
RANGE
DEFAULT
Network Type
The type of use of the code is defined as directed to the PSTN
(carrier) or a Networked system.
NET /
PSTN
NET
Numbering
Plan Code
This field defines the digits, 0 ~ 9 that make up a Network
Numbering Plan code. An ‘*’ will represent any digit. To assign the
code for the stations in another system, enter the common station
number digits followed by “#.”
Max. 16 digits(Include * and #)
Refer to
description
Networking CO
Group
The Numbering Plan CO Group indicates the Network CO/IP
Group that is used for the connection. A ‘00’ entry is an internal
net station number.
00-24
CPN ISDN
Information
When an ISDN Line is used to place a network call, the CPN
ISDN Information and the network Number are used as the Called
party number.
Max. 16
digits
CPN
Information
When a VoIP channel is used to place a network call, the CPN
used is the IP address associated with the VoIP channel.
 1: 00 CPN INFORMATION 01
 2: 00 CPN INFORMATION 02
 3: 00 CPN INFORMATION 03
 4: 00 CPN INFORMATION 04
Enter IP
address
Setup Wait
Response Time
Networking call-setup failure timer when there is no proceeding
message from the network (i.e., IP-Network is down)
0, 3~15
Sec.
0
ALT Speed Bin
Should the Network path fail, the system can place the call over
an alternative path using a System Speed Dial number.
eMG80/100:2000~4999, eMG800:2000~9999,
UCP: 20000~31999
Refer to
description
MPB IP
Address
This field is the IP Address of the destination system for the code
0.0.0.0
MPB Port
number
The TCP/IP port number of the destination system for the Net
Numbering Plan code is defined.
0000-9999
5588
Digit Repeat
When the number plan code, see above, is for PSTN call or
transit-call, the number code can be included in the SETUP
message.
Yes
No
No
PSTN Enblock
When a PSTN receives a Transit-out call from a networked user,
the digits can be sent En-block (YES) or Over-lap (NO).
Yes
No
No
PSTN CLI
Method
The CLI sent with the call for this code can be set as the NET CLI
(station number) or PSTN, which sends the CLI configured for the
CO/IP Line and Station CLI.
NET
PSTN
NET
CO Attendant
Code CLI
When a networked system places a transit outcall, the Centralized
ATD CLI can be sent.
OFF
ON
OFF
Firewall
Routing
When the system can communicate with the networked system
directly, over a common VPN, the system's Non-Firewall address
is sent in IP packets (OFF). Otherwise, the Firewall IP address is
sent (ON).
OFF
ON
ON
