iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
33
Numbering Plan
The system employs one of the nine (9) basic Flexible Number Plans as detailed in Appendix B. Individual
items from the selected Numbering Plan can be changed under Flexible Numbering Plan in section 4.4.1.7.
Note) The numbering plan on this manual is based on Numbering plan 2. The value (or feature code) may be
different according to the Numbering plan.
eMG80
Flexible VMIU/VOIU(MPB) channel & Flexible VMIB/VOIB(VVMU) channel
You can select one of the following types according to the current configuration using Voice mail and VoIP
channel
Flexible VMIU/VOIU(MPB) channel
Flexible VMIB/VOIB(VVMU) channel
VMIU8 / VOIU0
VMIB8 / VOIB4
VMIU8 / VOIU2
VMIB6 / VOIB6
VMIU8 / VOIU4
VMIB4 / VOIB8
VMIU6 / VOIU6
VMIU4 / VOIU8
1) The administrator can select the channel capacity of VoIP and Voice Mail in this field.
In the case of VMIU8/VOIU0, the default 2 channels of VoIP can't be used.
2) VVMU channel field can't be available if VVMU is not installed.
3) Select VoIP and Voice mail channel for Built-in (MPB) and VVMU by referring to the below chart.
Item
Specification
VOIU(MPB)
Built-in VoIP
Max. 8 Channels
- 2 Channels (by default)
- 6 Channels (1 Channel increment by license)
VMIU(MPB)
Built-in Voice Mail
Max. 8 Channels
- 2 Channels (by default)
- 6 Channels (1 Channel increment by license)
VOIB(VVMU)
VoIP
Max. 8 Channels
- 8 Channels (1 Channel increment by license)
VMIB(VVMU)
Voice Mail
Max. 8 Channels
- 8 Channels (1 Channel increment by license)
