iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
43
Table 4.4.1.4-1 SYSTEM IP ADDRESS PLAN
ATTRIBUTE
DESCRIPTION
DEFAULT
Second System Net
Mask
Net mask of the second private IP addresses
255.255.255.0
Firewall IP Address
When the system is installed behind a NAPT server, the fixed
IP Address provided by the NAPT server must be assigned
here. Also, use this IP address to identify the MPB (UCP) in
remote devices.
0.0.0.0
DDNS Usage of Firewall
If the firewall of the system has a dynamic IP address, you can
use Dynamic DNS by setting 'DDNS Usage of Firewall' and
'Domain Name of Firewall.' Note that the VOIP (UCP) / VOIU
(eMG)board will be restarted after the firewall's IP address is
changed.
ON/OFF,
1-127 (Min.)
Domain Name of Firewall
First MAC Range
MAC Address Range to register a device if device MAC
address is included in the range.
000000000000~
000000000000
Second MAC
Range
MAC Address Range to register a device if device MAC
address is included in the range.
000000000000~
000000000000
DNS IP Address
The IP Address of the Domain Name Server is the iPECS
system that will use to resolve a URL to an IP address. The
DNS provides the resolution after receiving the name from
iPECS.
0.0.0.0
System IPV6 Usage
Usage of IPV6 Address in SIP signaling
No
System IPV6 Address
IPV6 address used for System - User can set Unicast IP or set
based on SLAAC Info.
System IPV6 Router
IPV6 Router used for System - User can set Router IP or set
based on SLAAC Info.
System IPV6 Net Prefix
IPV6 Prefix used for System - User can set Prefix or set based
on SLAAC Info.
64
