iPECS UCP600 - Page 621

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
180
Table 3.3.6.10-1 BUTTON LED FLASH RATE (PGM 170)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
35
DSS OFF DUTY
FLASH 120 IPM
DSS button station in Hunt DND.
00-14
FLASH 120
IPM (10)
36
CALLBK
FLASH OFF
Message wait (call back).
00-14
FLASH OFF
Table 3.3.6.10-2 FLASH RATE TABLE (PGM 170)
Flash Rate
DESCRIPTION
00
Flash OFF
01
Steady On
02
30 ipm flash (30% On)
03
60 ipm flash (30% On)
04
60 ipm double wink (30% On-Off-On-Off & 70% On)
05
240 ipm flash (30% On)
06
240 ipm flutter (30% On-Off-On-Off-On & 70% Off)
07
480 ipm flash (30% On)
08
480 ipm flutter (30% On-Off-On-Off-On & 70% Off)
09
15 ipm flash (30% On)
10
120 ipm flash (30% On)
11
120 ipm flutter (30% On-Off-On-Off-On & 70% Off)
12
30 ipm double flash (30% On-Off-On & 70% Off)
13
480 ipm double wink (30% On-Off-On-Off & 70% On)
14
480 ipm double flash (30% On-Off-On & 70% Off)
4.3.6.11 Music Sources – PGM 171
Music inputs are provided for use as the Background Music and/or Music-On-Hold source inputs. MPBs
provide for two (2) music inputs.
The first input is the internal source and the second is external. In addition, a VMIU or VMIB announcement
may be recorded and played as MOH to a holding caller. And SLIB port is used as MOH to a holding caller.
PROCEDURE
MUSIC ASSIGN
PRESS FLEX KEY (1-6)
Press the [PGM] button and dial 171.
Select the desired Flex button; refer to Table 3.3.6.11-1.
Use the dial-pad to select the desired Music Source, refer to Table 3.3.6.11-1.
To save the Music Source, press the [Save] button.
