iPECS UCP600 - Page 687

iPECS eMG80/100& eMG800 & UCP & vUCP
Administration and Programming Manual Issue 2.5
246
PROCEDURE:
WEEKLY TIME TABLE
DIAL DIGIT (00-15)
Press the [PGM] button and dial 233 and enter Dial digit
(Ex.00).(eMG80/100:00~15/eMG800:00~32)
WEEKLY TIME TBL 0
PRESS FLEX KEY (1-7)
Use the dial-pad to enter a tenant Table index or 00 for the system (00~15).
Press the Flex button 1~7 for the desired day of the week (Monday ~Sunday)
followed by Flex button 1~3 for the desired ring mode (Day, Night, Timed),
refer to Table 3.3.9.9-1.
Use the dial pad to enter a time (military time), 0000 to 2359.
Press the [Save] button to store the data entry.
Table 3.3.9.9-1 AUTO RING MODE ASSIGNMENT (PGM 233)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
1
MON DAY-09:00 NITE-18:00
TDS-..:.. TDE-..:..
Monday DAY/NIGHT/TIMED ring
mode start times and TIMED mode
end times.
0000~2359
DAY: 9:00
NITE: 18:00
TDS: ..:..
TDE: ..:..
2
TUE DAY-09:00 NITE-18:00
TDS-..:.. TDE-..:..
Tuesday DAY/NIGHT/TIMED ring
mode start times and TIMED mode
end times.
0000~2359
DAY: 9:00
NITE: 18:00
TDS: ..:..
TDE: ..:..
3
WED DAY-09:00 NITE-18:00
TDS-..:.. TDE-..:..
Wednesday DAY/NIGHT/TIMED ring
mode start times and TIMED mode
end times.
0000~2359
DAY: 9:00
NITE: 18:00
TDS: ..:..
TDE: ..:..
4
THU DAY-09:00 NITE-18:00
TDS-..:.. TDE-..:..
Thursday DAY/NIGHT/TIMED ring
mode start times and TIMED mode
end times.
0000~2359
DAY: 9:00
NITE: 18:00
TDS: ..:..
TDE: ..:..
5
FRI DAY-09:00 NITE-18:00
TDS-..:.. TDE-..:..
Friday DAY/NIGHT/TIMED ring mode
start times and TIMED mode end
times.
0000~2359
DAY: 9:00
NITE: 18:00
TDS: ..:..
TDE: ..:..
6
SAT DAY-09:00 NITE-18:00
TDS-..:.. TDE-..:..
Saturday DAY/NIGHT/TIMED ring
mode start times and TIMED mode
end times.
0000~2359
DAY: 9:00
NITE: 18:00
TDS: ..:..
TDE: ..:..
7
SUN DAY-09:00 NITE-18:00
TDS-..:.. TDE-..:..
Sunday DAY/NIGHT/TIMED ring
mode start times and TIMED mode
end times.
0000~2359
DAY: 9:00
NITE: 18:00
TDS: ..:..
TDE: ..:..
