Table 3.3.10.4-1 NETWORK NUMBERING PLAN (PGM 324)
BTN
ATTRIBUTE/DISPLAY
DESCRIPTION
RANGE
DEFAULT
9
001 NET PSTN ENBLOCK
(0:NO/1:YES) : NO
Choose “Transit-out Public Line” to En-
block or Over-lap.
0: NO
1: YES
NO
10
001 CO ATD CODE CLI
(1:ON/0:OFF) : OFF
Determine whether if Centralized ATD CLI
is sent or not when the slave system
makes a transit call.
0: OFF
1: ON
OFF
11
001 FIREWALL ROUTING
(1:ON/0:OFF) : ON
Select the IP address (Firewall IP address
or Non-firewall IP address). If the
destination system (VOIB) is in the same
VPN, then a Non-firewall IP address
should be sent. Otherwise, the firewall IP
address should be sent.
 ON: Send firewall IP address
 OFF: Send Non-firewall (Internal) IP
address
0: OFF
1: ON
ON
12
001 AUTH CODE COS USE
(0:NO/1:YES): NO
When there‘s transit out call request from
the user of slave system by seizing CO
line, apply COS according to the
authorization code.
0: NO
1: YES
NO
13
001 SMDR DIAL HIDDEN
(0:NO/1:YES): NO
Determine to display dialed digit of transit
outcall or not at the slave system; it can
contain authorization code.
0: NO
1: YES
NO
14
001 NET PSTN CLI
(0:NET/1:PSTN): NET
NET: Send network station number for
CLI PSTN: Send full CLI (e.g., 02-450-
1000)
0: NET
1: PSTN
NET
15
001 SITE NAME
.............
It is a comment field to set the name of
the network site.
Max. 12
characters
16
001 EMERGENCY RERTETMR
(00-10) : 00
When the timer is ‘0’: The reroute
emergency call is not working. When the
timer is set ‘1’~’10’: The reroute
emergency call is activated after this
timer. This only works when PGM 112-
18th is transit-out CO group.
00-10
00
