K117sm5e7
5-95
16. On both sides
, reinstall the Spring Plates (14) with the screws (13).
If there is Spacer(s), fix them together.
17. On the right side, reinstall the terminal plate (12) with the screw (11).
The tab parts should fit in the notch on the frame.
18. Reconnect 2 connectors (10). Put the harnesses (9) in the wire saddles (8).
13 13
1414
11
tab
8
8
8
8
8
10
9
12 tab
To Next Page
