9-4
3. Removing Guide Plate
1. On the right side, open 2 wire saddles (1) and remove 2 screws (2) to remove the bracket (3).
2. Remove 1 screw (4) to remove the switch cover (5).
3. On the left side, remove 1 screw (6).
2
1
2
3
4
5
6
