9-8
4. Attach the Dehumidify Heater Assy to the Roll Deck Assy with 2 tooth washer screws (6) of the kit.
4-2. Installing Cover 6 Assy
1. Apply the Cover 6 Assy (1) to the inside of the Roll Deck Cover (2).
6
6
1
2
NOTE
Match the bottom end of the Cover 6 Assy with the
Roll Deck Cover’s rim.
1
2
Align sides
No jutting
