KIP 700m - Page 634

K117sm9e2
9-14
3. Remove 3 screws (5) to remove the switch case (1).
4. Connect the connector (6) in the switch case to the back of Switch (4).
5. Reinstall the switch case with 3 screws (5).
6
4 6
NOTE
Connect the connector in either way.
5 5
5
1
5 5
5
