KIP 700m - Page 637

K117sm9e2
9-17
4. Return the switch cover (10) in the original position. Connect the connector (11).
5. With pressing the switch cover (10) to the arrow direction (outward and downward), fix it with 1 screw (12).
6. With pressing the switch cover (14) to the arrow direction (outward and downward), fix it with 1 screw (13).
10
11
12
10
14
13
14
