KIP 700m - Page 638

K117sm9e2
9-18
7. Pass the harness of Dehumidify Heater Assy (16) through the round hole on the bracket (15).
Path the harness of Clutch (17) through the edge saddle (18).
8. Fix the bracket with 2 screws (19). Secure the harness (16) and the AC harness (20) with the wire saddles
(21).
15
16
17 18
20
16
19
19
21
