K117sm9e3
9-25
Confirm the following parts are attached to the “Paper Tray Kit”.
Table Assy
1
Base Assy
1
Connector Bracket
1
Gasket
1
Bind Screw
2
Procedure
1 this leaflet
Usage Precautions
1
Dimension (approx.)
(with installed, starting at printer body
345mm (D)
660mm (D), 50mm (H) (with the tray extended, maximum)
Power Supplied via the machine
Available Printer KIP 700m
To Next Page
