214323 280 Revision A
6. Start engine and lower header.
7. Stop engine and remove key from ignition.
NOTE:
The CA25 Combine Adapter is equipped with a multicoupler that connects to the combine. If combine is
equipped with individual connectors, a multicoupler kit (single-point connector) must be installed. Refer to Table
4.1, page 280 for a list of kits and installation instructions that are available through your combine Dealer.
Table 4.1 Multicoupler Kits
Combine
Kit Number
Challenger
71530662
Gleaner R/S Series
71414706
Massey Ferguson
71411594
Figure 4.25: Float Lock in UNLOCK Position
8. Disengage each adapter float lock by moving latch (A)
away from adapter and moving both header float lock
levers (B) down (UNLOCK).
HEADER ATTACHMENT/DETACHMENT
