1 – 81
Chapter 1 Troubleshooting
OCT Option
4.7 Error/Status Code List
Table 1-1
Status Code Error Contents Error Description
FIP to be
referred
STATUS 3-1 JS0
STATUS 3-1 to 3-5 indicates JAM by combina-
tion of Table 1-1.
STATUS 3-2 JS1
STATUS 3-3 JS2
STATUS 3-4 JS3
STATUS 3-5 JS4
STATUS 16-5 Full Stack (OCT) -Option OCT became Full Stack. FIP3.6
STATUS 17-2 OCT Cover Open - Cover of Option OCT is open. FIP3.1
STATUS 17-5 OCT Unit Fail
- Option OCT is not installed when OCT mode
is selected.
FIP3.2
FIP3.7
STATUS 21-1 Illegal Size (Duplex/OCT)
- Paper size that is not supported in Duplex or
OCT mode is selected.
FIP2.6
FIP3.5
JS4 JS3 JS2 JS1 JS0 Contents of Jam Error Description
FIP to
be
referred
0 1 1 0 1 OCT Jam 1
Paper Jam/Exit to OCT - When the
paper did not reach to OCT Sensor
from Exit Sensor within the specified
time.
FIP3.3
1 0 1 0 1 OCT Jam 2
Paper Jam/OCT -When the paper was
not fed to OCT Sensor within the speci-
fied time. - When OCT Sensor turned
ON in warming up.
FIP3.4
To Next Page
