1 – 91
Chapter 1 Troubleshooting
FIP3.10 MOTOR ASSY OFFSET
Step Check Yes No
Possible causes:
MOTOR ASSY OFFSET (PL23.1.20)
MOTOR ASSY OCT (PL23.1.6)
PWBA OCT (PL23.1.22)
HARNESS ASSY OCT2 (PL23.1.25)
HVPS/MCU (PL12.1.19)
HARNESS ASSY OCT1 (PL12.1.26)
1
Checking MOTOR ASSY OFFSET
Not using DIAG tool: Replace MOTOR ASSY OFF-
SET.(RRP23.8)
Is the problem cleared?
End of work Go to step 4.
Using DIAG tool: Does the offset of CHUTE OFFSET
ASSY operate normally?
Check using Chapter 2 Diagnostic [OCT Offset Test].
Go to step 2. Go to step 3.
2 Is the problem cleared? End of work
Go to FIP3.8
PWBA OCT.
3
Checking MOTOR ASSY OFFSET
Replace MOTOR ASSY OFFSET. (RRP23.8)
Is the problem cleared?
End of work Go to step 4.
4
Checking HARNESS ASSY OCT2 for continuity
Disconnect P/J70 from PWBA OCT.
Remove HARNESS ASSY OCT2.
Is there continuity between J70 and J3070?
Go to step 5.
Replace HAR-
NESS ASSY
OCT2.
5
Checking HARNESS ASSY OCT1 for continuity
Remove HARNESS ASSY OCT1.
Is there continuity between J30 and J3070?
Go to step 6
Replace HAR-
NESS ASSY
OCT1.
6
Checking PWBA OCT
Replace PWBA OCT. (RRP23.7)
Is the problem cleared?
End of work
Replace HVPS/
MCU. (RRP12.10)
To Next Page
