1 – 13
Chapter 1 Troubleshooting
FIP1.3 Fuser Error
Step Check Yes No
Possible causes:
FUSER ASSY (PL8.1.20) HVPS/MCU (PL12.1.19)
LVPS (PL12.1.5)
HARNESS ASSY FUSER (PL8.1.17)
HARNESS ASSY
LVPS (PL12.1.1)
1
Checking the thermistor for operation.
Does Error occur soon after the power is turned ON?
Error occurs as soon as the power is turned ON, or just
after the time when a short warm up period elapsed.
Replace FUSER
ASSY. (RRP8.8)
Go to FIP1.27
FUSER ASSY.
To Next Page
