8 - 7
Chapter 8 Printer Specifications
3.7 Face Up Tray Size and Weight (REF)
3.8 Minimum Space Requirements
There must be sufficient space around the print engine for proper access, ventilation and operation.
Condition Width (mm) Depth (mm) Height (mm) Weight (kg)
Unpacked
(Installation)
320.6
162.6 89.4
0.25
Unpacked
(Simple)
169.6 43.0
Packaged 360.0 200.0 95.0 0.6
W
D
JG8711AA
H
200 mm
300 mm
930 mm
JG8103AA
12 mm
1110 mm
255 mm
10 mm
402 mm
