Chapter 1 Troubleshooting
FIP1.11 EP Cartridge
Step Check Yes No
Possible causes:
HVPS/MCU (PL12.1.19)
EP CARTRIDGE
GUIDE ASSY CRU R (PL8.1.25)
1
Checking EP CARTRIDGE (1)
Is the EP CARTRIDGE appropriate model?
Remove the EP CARTRIDGE to check the model.
Go to step 2.
Replace EP CAR-
TRIDGE.
2
Checking EP CARTRIDGE (2)
Install the EP CARTRIDGE again.
Does STATUS 1-6 occur again when the power is
turned ON?
Go to step 3. End of work
3
Checking GUIDE ASSY CRU R
Remove GUIDE ASSY CRU R. (RRP8.13)
Is each harness continuous?
Go to step 4.
Replace GUIDE
ASSY CRU R.
(RRP8.13)
4
Checking EP CARTRIDGE (3)
Replace the EP CARTRIDGE.
Does Error occur again when the power is turned ON?
Replace HVPS/
MCU.
(RRP12.10)
End of work
