Chapter 4 Plug/Jack(P/J) Connector Locations
550 Sheet Feeder
4. Connector [P (plug) / J (jack)]
4.1 List of P/J
P/J Coordinates Remarks
80 I-208 Connects HARNESS ASSY SIZE FDR2 and PWBA FEEDER 550
81 H-208 Connects HARNESS LOW PAPER and PWBA FEEDER 550
82 H-208 Connects HARNESS ASSY FDR MOT and PWBA FEEDER 550
83 I-208 Connects HARNESS ASSY FDR2 and PWBA FEEDER 550
84 I-208 Connects HARNESS ASSY FDR5 and PWBA FEEDER 550
85 H-208 Connects HARNESS ASSY CLSNR2 and PWBA FEEDER 550
801 H-206 Connects HARNESS ASSY SIZE FDR1 and HARNESS ASSY SIZE FDR2
802 C-207 Connects HARNESS ASSY SIZE FDR1 and OPT ASSY SIZE
810 J-207 Connects SENSOR LOW PAPER and HARNESS LOW PAPER
820 G-206 Connects MOTOR FEEDER and HARNESS ASSY FDR MOT
852 I-207 Connects SENSOR NO PAPER and HARNESS ASSY CLSNR1
853 G-206 Connects CLUTCH ASSY PH and HANESS ASSY CLSNR1
854 H-206 Connects CLUTCH ASSY PR-REGI and HARNESS ASSY CLSNR1
855 J-207 Connects HARNESS ASSY CLSNR1 and HARNESS ASSY CLSNR2
2083 G-208 Connects HARNESS ASSY FDR1 and HARNESS ASSY FDR2
8483 G-209 Connects HARNESS ASSY FDR5 and HARNESS ASSY FDR5
