Oki B6500 - FIP1.35 SWITCH I;L ASSY (Interlock S;W Front R)

1 – 56
Chapter 1 Troubleshooting
FIP1.35 SWITCH I/L ASSY (Interlock S/W Front R)
Step Check Yes No
Possible causes:
SWITCH I/L ASSY (PL1.1.11)
LVPS (PL12.1.5)
HVPS/MCU (PL12.1.19)
1
Checking SWITCH I/L ASSY for continuity
Disconnect P/J411.
Is P/J411-1 and P/J411-2 continuous, when SWITCH I/
L ASSY is pushed, and not when released?
Go to step 2.
Replace SWITCH I/
L ASSY. (RRP1.6)
2
Checking HARNESS ASSY LVPS for continuity
Disconnect P/J11, P/J41 and P/J411.
Is there continuity between
P411-2 and J41-5?
P411-1 and J11-12?
Go to FIP1.24
LVPS.
Replace HAR-
NESS ASSY LVPS.
