3 - 177
Chapter 3 Removal and Replacement Procedures (RRPs)
RRP10.10COVER RIGHT (PL10.1)
Removal
1) Remove the 2 screws (gold tapping, 8mm) securing the COVER RIGHT.
2) 2) Remove the COVER RIGHT from the COVER HSG DUP (PL 10.1).
Replacement
1) Install the COVER RIGHT to the COVER HSG DUP (PL 10.1) using the 2 screws (gold tap-
ping, 8mm).
When installing, be sure to fit the positioning holes on the COVER RIGHT to the bosses
on the COVER HSG DUP.
COVER RIGHT
(PL21.1.41)
COVER HSG DUP
(PL21.1.18)
J23610AA
To Next Page
