1 – 98
Chapter 1 Troubleshooting
4.11 Level 1 FIP
FIP4.1 No Tray/Tray 3, 4
Step Check Yes No
Possible causes:
HVPS/MCU (PL12.1.19)
OPT ASSY SIZE (PL20.1.8)
Option 550 Paper Feeder 550 PAPER CASSETTE
(PL20.3.50)
1
Does Error still occur, after removing and reinstalling
the 550 PAPER CASSETTE of Option 550 Paper
Feeder on Tray 3 or Tray 4?
Go to step 2. End of work
2
Checking 550 PAPER CASSETTE
Are GUIDE ASSY END, GEAR SECTOR, RACK SIZE
and LINK SW SIZE1/2/3 of 550 PAPER CASSETTE of
Tray 3 or Tray 4 installed correctly?
Go to FIP4.10
OPT ASSY SIZE.
Reinstall the parts
causing Error.
To Next Page
