Oki B6500 Service Manual

1 – 70
Chapter 1 Troubleshooting
4.5 Level 1 FIP
FIP2.1 Option Duplex Cover Error
Step Check Yes No
Possible causes:
HVPS/MCU (PL12.1.19)
LVPS (PL12.1.5)
HSG LOWER DUP (PL21.1.6)
COVER HSG DUP (PL21.1.18)
SWITCH DUPLEX (PL21.1.27)
PWBA DUPLEX (PL21.1.32)
1
Checking COVER HSG DUP
Open COVER HSG DUP.
Is the rib on HSG LOWER DUP to push down SWITCH
DUPLEX damaged?
Replace HSG
LOWER DUP.
(RRP21.3)
With tool Go to step
2. Without tool Go
to FIP2.11 SWITCH
DUPLEX.
2
Checking SWITCH DUPLEX for function
Remove EP CARTRIDGE.
Does number of Sensor/Switch Check increase by one,
every time COVER HSG DUP is opened and closed?
Check using Chapter 2 Diagnostic [Sensor/Switch
Check].
Replace HVPS/
MCU.
(RRP12.10)
Go to FIP2.11
SWITCH DUPLEX.

Oki B6500 Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Flash memory	512 MB
Storage media	HDD
Internal memory	128 MB
Maximum internal memory	640 MB
Internal storage capacity	40 GB
Total input capacity	700 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Power requirements	230V
Standard media sizes	3\
Power consumption (active)	880 W
Compatible operating systems	Windows, XP (Home, Professional); 2000 (Workstation, Professional, Server, Advanced Server – SP4 +); NT 4.0 (Workstation, Server – SP6 +); ME; 98/98 SE; Mac OS 9.1+/10.1+; Unix (Sun Solaris 8, 7, 2.5; HP-UX 11.0/ 10.20); Linux (Redhat 6.x).
Envelopes sizes	C5, DL
Media weight (tray 1)	60 - 216 gsm
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
PCL fonts	86
Printer fonts	PCL, PostScript
Maximum duty cycle	200000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	110 W
Power consumption (printing)	1200 W

Weight and Dimensions

Dimensions (WxDxH)	422 x 465 x 404 mm
