3 - 178
Chapter 3 Removal and Replacement Procedures (RRPs)
RRP10.11MOTOR DUPLEX (PL10.1)
Removal
1) Remove the COVER LEFT (PL 10.1). (RRP10.9)
2) Remove the COVER TOP (PL 10.1). (RRP10.4)
3) Remove the PWBA DUPLEX (PL 10.1). (RRP10.5)
4) Remove the screw (silver, 6mm) securing the HARNESS ASSY DUP EARTH (PL 10.1)
5) Remove the 3 screws (gold tapping, 8mm) securing the BRACKET MOTOR (PL 10.1) to the
COVER HSG DUP (PL 10.1).
6) Remove the SPRING LATCH (PL 10.1) between the LEVER LATCH LEFT (PL 10.1) and
BRACKET MOTOR (PL 10.1).
7) Remove the BRACKET MOTOR together with the MOTOR DUPLEX and SWITCH DUPLEX
(PL 10.1).
When removing the BRACKET MOTOR, be careful not to lose the gears attached to the
COVER HSG DUP.
8)Remove the 2 screws (gold, 6mm) securing the MOTOR DUPLEX to the BRACKET
MOTOR.
9) Remove the MOTOR DUPLEX.
To Next Page
