Chapter 4 Plug/Jack(P/J) Connector Locations
Chapter 4 Print Engine Plug/Jack Connector Locations
1. Connector [P (plug) / J (jack)]
1.1 List of P/J
P/J Coordinates Remarks
1 G-104 Connects OPERATION PANEL and HARNESS ASSY PANEL
10 B-111 Connects HARNESS ASSY LVPS and HVPS/MCU
11 D-111 Connects HARNESS ASSY LVPS and HVPS/MCU
13 E-111 Connects HARNESS ASSY ROS and HVPS/MCU
14 E-112 Connects HARNESS ASSY ROS and HVPS/MCU
15 F-112 Connects HARNESS ASSY ANT and HVPS/MCU
16 G-111 Connects HARNESS ASSY ROS and HVPS/MCU
17 G-111 Connects HARNESS ASSY ROS and HVPS/MCU
18 F-112 Connects HARNESS ASSY LVPS and HVPS/MCU
20 H-111 Connects HARNESS ASSY FDR1 and HVPS/MCU
22 I-110 Connects HARNESS ASSY TONER1 and HVPS/MCU
24 J-110 Connects HARNESS ASSY CHUTE and HVPS/MCU
26 I-110 Connects HARNESS ASSY LOW PAPER SNR and HVPS/MCU
27 D-111 Connects HARNESS ASSY LVPS and HVPS/MCU
28 K-110 Connects FFC ASSY ESS and HVPS/MCU
29 K-108 Connects HARNESS ASSY EXIT SNR1 and HVPS/MCU
30 K-107 Connects HARNESS ASSY OCT1 and HVPS/MCU
31 C-111 Connects GUIDE ASSY CRU and HVPS/MCU
40 X-121 Connects HARNESS ASSY LVPS and LVPS
41 X-122 Connects HARNESS ASSY LVPS and LVPS
42 W-122 Connects HARNESS ASSY LVPS and LVPS
43 X-122 Connects MAIN MOTOR and LVPS
44 X-123 Connects INTERLOCK SW REAR and LVPS
45 X-123 Connects INTERLOCK SW 24V and LVPS
46 X-120 Connects HARNESS ASSY FUSER and LVPS
47 U-126 Connects HARNESS ASSY FUSER and LVPS
48 U-125 Connects HARNESS ASSY 100V and LVPS
101 V-120 Connects LVPS and PWBA EXIT MOTOR
102 U-120 Connects HARNESS ASSY LVPS and PWBA EXIT MOTOR
103 S-119 Connects MOTOR ASSY EXIT and PWBA EXIT MOTOR
131 B-111 Connects ROS ASSY and HARNESS ASSY ROS
