1 – 69
Chapter 1 Troubleshooting
Duplex Option
4.3 Error/Status Code List
4.4 Table 1
Status Code Error Contents Error Description FIP to be referred
STATUS 3-1 JS0
STATUS 3-1 to 3-5 indicates
JAM by combination of Table
1-1.
STATUS 3-2 JS1
STATUS 3-3 JS2
STATUS 3-4 JS3
STATUS 3-5 JS4
STATUS 17-3 Duplex Cover Open
-Cover of Option Duplex is
open.
FIP2.1
STATUS 17-6 Duplex Unit Fail
- Option Duplex removed after
powering on.
FIP2.2 FIP2.7
STATUS 21-1
Illegal Size (Duplex/
OCT)
- Paper size that is not sup-
ported in Duplex or OCT mode
is selected.
FIP2.6 FIP3.5
JS4 JS3 JS2 JS1 JS0
Contents of
Jam
Error Description
FIP to be
referred
0 0 1 0 0 Duplex Jam 1
Paper Jam/Dup to Regi -When the
paper reached Regi position from
Duplex Sensor earlier than the specified
time.
FIP2.4
0 1 1 0 0 Duplex Jam 2
Paper Jam/Exit to Dup -When the paper
did not reach Duplex Sensor within the
specified time.
FIP2.3
1 0 1 0 0 Duplex Jam 3
Paper Jam/Dup to Regi -When the
paper was not fed to Duplex Sensor
within the specified time. - When Duplex
Sensor turned ON in warming up.
FIP2.4
1 1 1 0 0
Duplex Jam 4
(Misfeed Jam)
Paper Jam/Misfeed -When the paper did
not reach Regi position from Duplex
Sensor within the specified time.
FIP2.5
To Next Page
