Chapter 3 Removal and Replacement Procedures (RRPs)
RRP12.12GEAR NUDGER (PL12.2)
Removal
1) While lifting up the boss of the HOLDER LEFT (PL 12.2.5) at the back of the 550 FEEDER
OPTION, shift the HOLDER LEFT in the direction of the arrow to remove the 3 hooks.
2) Remove the HOLDER LEFT from the SUPPORT NUDGER (PL 12.2.4). At the same time, the
ACTUATOR NO PAPER (PL 12.2.6) is removed.
3) Release the hook of the ROLL ASSY NUDGER (PL 12.2.11), and pull it out from the SHAFT
NUDGER (PL 12.2.9).
4) Release the hook of the GEAR NUDGER, and pull it out from the SHAFT NUDGER.
When removing, do not hold the rubber rollers of the ROLL ASSY NUDGER and GEAR
NUDGER.
