3 - 184
Chapter 3 Removal and Replacement Procedures (RRPs)
RRP11.OCT Option
RRP11.1 OCT Option
Removal
When removing the Option OCT, be careful not to drop the assembly.
1) Loosen the 2 SCREW THUNBs (PL 11.1) securing the OCT to the printer.
2) Lift up the OCT, and disconnect the connector (P/J3070) of the HARNESS ASSY OCT2 (PL
11.1) from the printer,
3) Release the 2 hooks at the bottom side of the COVER OCT (PL 11.1) from the printer, and
remove the OCT.
To Next Page
