Oki B6500

4 – 8
Chapter 4 Plug/Jack(P/J) Connector Locations
OCT Option
3. Connector [P (plug) / J (jack)]
3.1 List of P/J
P/J Coordinates Remarks
70 J-407 Connects HARNESS ASSY OCT2 and PWBA OCT
71 J-408 Connects MOTOR ASSY OCT and PWBA OCT
72 J-407 Connects MOTOR ASSY OFFSET and PWBA OCT
73 J-408 Connects HARNESS ASSY OCT SNR and PWBA OCT
74 I-407 Connects HARNESS ASSY REAR COVER and PWBA OCT
75 J-408 Connects SOLENOID ASSY GATE and PWBA OCT
710 F-405 Connects HARNESS ASSY OCT MOT and MOTOR ASSY OCT
730 F-408 Connects SENSOR OCT and HARNESS ASSY OCT SNR
740 I-407 Connects SWITCH REAR COVER and HARNESS ASSY REAR COVER
3070 J-410 Connects HARNESS ASSY OCT2 and HARNESS ASSY OCT1
