Chapter 8 Printer Specifications
3. Mechanical Properties
Dimensions shall be specified with nominal values including dimensional tolerances of +/- 5mm and +/-
0.5 kg. The dimensions shall not include any of the local projections including a lever and a handle.
3.1 Print Engine Size and Weight (REF)
The size and weight shall basically apply to the engine configuration.
:
1. These sizes exclude print engine’s side and rear louver, a rear knob and top bump.
2. Unpacked: Neither an EP cartridge nor a controller shall be included.
3. Packaged: An EP cartridge shall be included.
4. Depth size is the condition which telescope by the paper size.
Configura-
tion/Condi-
tion
Configuration
Width
(mm)
Depth (mm)
Height
(mm)
Weight
(kg)
Input Tray Exit To A4/Letter
To Legal
14
Unpacked
(Note 2)
550 500
421.8 465.4 524.0 404.3 21.1
Packaged
(Note 3)
570.0 554.0 590.0 27.3
JG8102AA
W
D
H
