1 – 53

Chapter 1 Troubleshooting

FIP1.32 INTERLOCK S/W 24V

Step Check Yes No

Possible causes:

INTERLOCK S/W 24V (PL8.1.11)

LVPS (PL12.1.5)

HVPS/MCU (PL12.1.19)

Checking INTERLOCK S/W 24V

Disconnect P/J45 from LVPS.

Is P/J45-1 and P/J45-3 continuous, when INTERLOCK

S/W 24V is pushed, and not when released?

Go to FIP1.24

LVPS.

Replace INTER-

LOCK S/W 24V.

(RRP8.5)
