1 – 12
Chapter 1 Troubleshooting
FIP1.2 ROS Error
Step Check Yes No
Possible causes:
ROS ASSY (PL8.1.1)
HVPS/MCU (PL12.1.19)
EP CARTRIDGE
HARNESS ASSY ROS (PL8.1.2)
LVPS (PL12.1.5)
1
Checking NVRAM for data setup value.
Are the values of NV03 (resolution) and the value of
NV04 (Laser Diode output) set at the initial setup value
in the factory?
Check using Chapter 2 Diagnostic [ADJUSTMENT
PARAMETER INITIALIZE MODE].
Go to FIP1.26
ROS ASSY.
Set NV03 and
NV04 to factory
setup, and then
check again. If
Error still occurs,
go to FIP1.26 ROS
ASSY.
To Next Page
