1 – 28
Chapter 1 Troubleshooting
FIP1.13 No Tray/Tray 1, 2
Step Check Yes No
Possible causes:
GUIDE TRAY LEFT (PL7.1.7)
150 PAPER CASSETTE (PL2.1.50)
HVPS/MCU (PL12.1.19)
550 PAPER CASSETTE (PL4.1.50)
1 Does Error occur with Tray 3 or Tray 4?
Go to FIP4.1 "No
Tray/Tray 3.4".
Go to step 2.
2
Does Error still occur, after removing and reinserting
the Paper Cassette of Tray 1 and Tray 2?
Go to step 3. End of work
3
Checking Paper Cassette
Are GUIDE ASSY END, GEAR SECTOR, RACK SIZE,
LINK SW SIZE1/2/3 of Paper Cassette of Tray 1 or Tray
2 installed correctly?
Go to FIP2.17
GUIDE TRAY
LEFT.
Reinstall the
obstructive parts.
To Next Page
