Oki B6500

8 - 12
Chapter 8 Printer Specifications
4.2.4 Duplex Unit (Option)
This unit is capable of printing on both sides of the paper.
1. Media Size
- Width: 88.9mm ~ 215.9mm
- Length: 139.7mm ~ 355.6mm
2. Media Weight
- 64gsm (17.1lb) ~ 216gsm (80lb)
- Duplex Mode: 64gsm (17.1lb) ~ 216gsm (80lb)
3. Media Stack Capacity
- Capability to duplex print from the cassette input is supported by the engine for the 13 paper
sizes shown in the table above in 1 sheet batch mode.
Paper size except for the above 13 paper sizes is supported as a custom.
4.3 Paper Output Tray
:
Paper shall be flipped over if the feeding performance does not meet with face side.
4.3.1 500 Sheet Face Down Output Tray
Under normal conditions (22
o
C, 55-60%RH), the print engine output tray has a capacity of 500 sheets
of face-down output on the top cover, assuming the following paper. This applies to newly-opened paper
which has been rested in the packaged condition for more than 12 hours in the operating environment.
- A4 (SEF): 500 sheets
- 20 lb Letter: 500 sheets
No. Type Size (mm x mm)
1 Letter SEF 215.9 x 279.4
2 A4 SEF 210.0 x 297.0
3 Legal 13” SEF 215.9 x 330.2
4 Legal 14” SEF 215.9 x 355.6
5 B5 (JIS) SEF 182.0 x 257.0
6 B5 (ISO) SEF 176.0 x 250.0
7 Executive SEF 184.2 x 266.7
8 Statement SEF 139.7 x 215.9
9 A5 SEF 148.0 x 210.0
10 1/3 A4 SEF 99.0 x 210.0
11 A6 Postcard 105.0 x 148.0
12 Japanese Postcard 100.0 x 148.0
13 US Postcard 88.9 x 139.7
