Chapter 6 Principles of Operation
12.2 Layout of Paper Transport Path
Main components regarding the transport of the paper when the Option OCT is
installed are given below.
ROLL ASSY FEED
ROLL ASSY RETARD
ROLL ASSY NUDGER
ROLL ASSY TURN
ROLL PINCH TURN
ROLL DUP
ROLL
PINCH
ROLL PINCH EXIT
JG6814AA
ROLL EXIT
ROLL OCT UPPER
ROLL OCT LOWER
ROLL PINCH
ROLL PINCH OCT
ROLL FU
ROLL PINCH FU
