Oki B6500 Service Manual

3 - 206
Chapter 3 Removal and Replacement Procedures (RRPs)
RRP11.11ROLL OCT LOWER (PL11.1)
Removal
1) Remove the COVER REAR (PL 11.1). (RRP11.2)
2) Remove the COVER OCT (PL 11.1). (RRP11.4)
3) Remove the 2 screws (gold tapping, 8mm, gold 6mm) securing the SUPPORT OCT LEFT (PL
11.1).
4) Remove the 2 screws (gold tapping, 8mm) securing the BRACKET MOTOR OCT (PL 11.1).
5) Disconnect the harness conector of the MOTOR ASSY OCT , and remove the BRACKET
MOTOR OCT together with the MOTOR ASSY OCT (PL 11.1).
6) Remove the GEAR 45 (PL 11.1), GEAR 19/37 (PL 11.1) and GEAR 19 (PL 11.1).
7) Release the hook of the BEARING ROLL (PL 11.1) on the side of GEAR 19 , and remove it
from the HOUSING OCT (PL 11.1).
Be careful handling the hook of the BEARING ROLL. It is fragile and could break ifgiven
excessive force.
8) Shift the ROLL OCT LOWER in the direction of the arrow to remove.
When removing, do not hold the rubber rollers of the ROLL OCT LOWER.

Oki B6500 Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Flash memory	512 MB
Storage media	HDD
Internal memory	128 MB
Maximum internal memory	640 MB
Internal storage capacity	40 GB
Total input capacity	700 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Power requirements	230V
Standard media sizes	3\
Power consumption (active)	880 W
Compatible operating systems	Windows, XP (Home, Professional); 2000 (Workstation, Professional, Server, Advanced Server – SP4 +); NT 4.0 (Workstation, Server – SP6 +); ME; 98/98 SE; Mac OS 9.1+/10.1+; Unix (Sun Solaris 8, 7, 2.5; HP-UX 11.0/ 10.20); Linux (Redhat 6.x).
Envelopes sizes	C5, DL
Media weight (tray 1)	60 - 216 gsm
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
PCL fonts	86
Printer fonts	PCL, PostScript
Maximum duty cycle	200000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	110 W
Power consumption (printing)	1200 W

Weight and Dimensions

Dimensions (WxDxH)	422 x 465 x 404 mm
