1 – 55
Chapter 1 Troubleshooting
FIP1.34 INTERLOCK S/W REAR
Step Check Yes No
Possible causes:
INTERLOCK S/W REAR (PL12.1.7)
LVPS (PL12.1.5)
HVPS/MCU (PL12.1.19)
1
Checking INTERLOCK S/W REAR for continuity
Disconnect P/J44 from LVPS.
Is P/J44-1 and P/J44-3 continuous, when INTERLOCK
S/W REAR is pushed, and not when released?
Go to FIP1.24
LVPS.
Replace INTER-
LOCK S/W REAR.
(RRP12.5)
To Next Page
