Oki B6500 Service Manual

4 – 6
Chapter 4 Plug/Jack(P/J) Connector Locations
Duplex Transport Option
2. Connector [P (plug) / J (jack)]
2.1 List of P/J
P/J Coordinates Remarks
50 H-308 Connects HARNESS ASSY DUP and PWBA DUPLEX
51 H-308 Connects MOTOR DUPLEX and PWBA DUPLEX
52 H-308 Connects HARNESS ASSY DUP COVER and PWBA DUPLEX
53 F-307 Connects HARNESS ASSY DUP SNR and PWBA DUPLEX
54 F-307 Connects FAN DUPLEX and PWBA DUPLEX
56 H-309 Connects HARNESS ASSY DUP EARTH and PWBA DUPLEX
520 I-309 Connects SWITCH DUPLEX and HARNESS ASSY DUP
530 C-306 Connects SENSOR DUP and HARNESS ASSY DUP SNR
560 I-311 Connects HARNESS ASSY DUP EARTH and EARTH ASSY PLATE
2750 I-308 Connects HARNESS ASSY DUP and HARNESS ASSY LVPS

Oki B6500 Specifications

General

Color	No
Duplex printing	Yes
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	45 ppm
Flash memory	512 MB
Storage media	HDD
Internal memory	128 MB
Maximum internal memory	640 MB
Internal storage capacity	40 GB
Total input capacity	700 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Power requirements	230V
Standard media sizes	3\
Power consumption (active)	880 W
Compatible operating systems	Windows, XP (Home, Professional); 2000 (Workstation, Professional, Server, Advanced Server – SP4 +); NT 4.0 (Workstation, Server – SP6 +); ME; 98/98 SE; Mac OS 9.1+/10.1+; Unix (Sun Solaris 8, 7, 2.5; HP-UX 11.0/ 10.20); Linux (Redhat 6.x).
Envelopes sizes	C5, DL
Media weight (tray 1)	60 - 216 gsm
Non-ISO print media sizes	Executive (184 x 267mm), index card, Letter (media size), Statement (140 x 216mm), Legal (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
PCL fonts	86
Printer fonts	PCL, PostScript
Maximum duty cycle	200000 pages per month
Number of PostScript fonts	136
Power consumption (standby)	110 W
Power consumption (printing)	1200 W

Weight and Dimensions

Dimensions (WxDxH)	422 x 465 x 404 mm
