Chapter 1 Troubleshooting
FIP1.22 Face Up Tray Error
Step Check Yes No
Possible causes:
HVPS/MCU (PL12.1.19)
SENSOR FACE UP OPEN (PL10.1.25)
GATE FU (PL10.2.6)
LEVER GATE FU (PL10.2.17)
1
Checking Actuator for operation
Does ACTUATOR FULL STACK in GATE FU move
smoothly, when moving LEVER GATE FU up and
down?
With tool Go to
step 2. Without
tool Go to step3.
Replace GATE FU.
2
Checking SENSOR FACE UP for operation
Remove EP CARTRIDGE.
Does the number of Sensor/Switch Check increase by
one, every time moving LEVER GATE FU up and
down?
Check using Chapter 2 Diagnostic [Sensor/Switch
Check].
Go to step 3.
Go to FIP1.44
SENSOR FACE
UP OPEN.
3
Checking SENSOR FACE UP OPEN for operation
Replace SENSOR FACE UP OPEN.
Does the problem still occur, after replacing SENSOR
FACE UP OPEN?
Replace HVPS/
MCU.
(RRP12.10)
End of work
