Oki B6500 - FIP1.16 Drum Life

1 – 31
Chapter 1 Troubleshooting
FIP1.16 Drum Life
Step Check Yes No
Possible causes:
EP CARTRIDGE
GUIDE ASSY CRU R (PL8.1.25)
HVPS/MCU (PL12.1.19)
1
Checking EP CARTRIDGE
Does Error still occur, after installing a new EP CAR-
TRIDGE?
Go to step 2. End of work
2
Checking GUIDE ASSY CRU R for continuity
Remove EP CARTRIDGE.
Remove GUIDE ASSY CRU R. (RRP8.13)
Is each cable of each harness continuous?
Replace HVPS/
MCU.
(RRP12.10)
Replace GUIDE
ASSY CRU R.
(RRP8.13)
