Oki B6500

6 – 33
Chapter 6 Principles of Operation
Duplex Option
8. Driving Force Transmission Path
8.1 MOTOR DUPLEX
The rotating force of the MOTOR DUPLEX is transmitted via various gears to
components that need mechanical driving force as shown in the flow given below.
8.2 Gear Layout
J26611AA
MOTOR DUPLEX
GEAR IDLE 57/37
GEAR ROLL
GEAR IDLE 77
GEAR IDLE 47
GEAR IDLE 29
GEAR ROLL
GEAR IDLE 57/37
GEAR ROLL
GEAR IDLE 29
GEAR IDLE 47
GEAR IDLE 77
GEAR IDLE 57/37
GEAR ROLL
MOTOR DUPLEX
J26612AA
