8 - 2
Chapter 8 Printer Specifications
2. Electrical Properties
2.1 Power Source
Two types of power source as follows are available for this printer, which are selected according to the
specifications.
2.1.1 For 120 VAC Printer
2.1.2 For 220/240 VAC Printer
2.2 Power Consumption
2.2.1 Maximum Power Consumption
:
1. No electrical current shall be supplied to the Fuser unit in Low Power Mode.
2. No electrical current shall be supplied to the Fuser / Fan / MCU unit in Sleep Mode.
3. Power consumption is without the Controller.
4. Specified with FX method.
5. The controller consuming current at low power mode 2 and sleep mode shall not
exceed 1A @ 3.3V and 0.5A @ 5V.
2.2.2 Average Power Consumption
Voltage Frequency
Min Nominal Max Min Nominal Max
98VAC 120VAC 132VAC 47Hz 50/60Hz 63Hz
Voltage Frequency
Min Nominal Max Min Nominal Max
198VAC 220/240VAC 264VAC 47Hz 50/60Hz 63Hz
Operation
(+/- 10%)
Power
Consumption
Electrical
Current
Power Consumption
Low Power
Mode 1
Low Power
Mode 2
Sleep Mode
*5
(Fan Stop)
Fan Low
Speed
Fan Stop
*5
110 VAC
Maximum:
1210 W
Maximum:
12.2 A
Maximum:
16.5 W
Maximum:
6.5 W
Maximum:
3.5 W
220 VAC
Maximum:
1270 W
Maximum:
5.8 A
Maximum:
17.6 W
Maximum:
9.0 W
Maximum:
5.0 W
Input
Voltage
Base w/OCT and Option Feeder
Standby Simplex Duplex
120 VAC 110 W 880 W 629 W
230 VAC 89 W 728 W 633 W
