3 - 205
Chapter 3 Removal and Replacement Procedures (RRPs)
Replacement
1) Install the SENSOR OCT to the HOUSING OCT (PL 11.1), and secure it with the hooks.
2) Move the ACTUATOR OCT in the opposite direction of the arrows, and secure it with the
hooks.
3) Install the SPRING ACTUATOR (PL 11.1).
Install the SPRING ACTUATOR to the ACTUATOR OCT as shown in the figure.
4) Connect the connector (P/J730) of the HARNESS ASSY OCR SNR (PL 11.1) to the SENSOR
OCT.
5) Secure the HARNESS ASSY OCT SNR with the hooks.
6) Install the COVER FRONT (PL 11.1). (RRP11.5)
7) Install the COVER OCT (PL 11.1). (RRP11.4)
8) Install the COVER REAR (PL 11.1). (RRP11.2)
To Next Page
