Chapter 4 Plug/Jack(P/J) Connector Locations
140 A-108 Connects ROS ASSY and HARNESS ASSY ROS
141 R-119 Connects HARNESS ASSY LVPS and INTERLOCK SW 5V
150 M-121 Connects PWBA ASSY ANT and HARNESS ASSY ANT
160 A-108 Connects ROS ASSY and HARNESS ASSY ROS
170 A-107 Connects ROS ASSY and HARNESS ASSY ROS
180 A-109 Connects SIZE1 Tray and HARNESS ASSY LVPS
210 A-110 Connects SIZE2 Tray and HARNESS ASSY LVPS
220 R-127 Connects SENSOR TONER and HARNESS ASSY TONER1
221 M-124 Connects HARNESS ASSY TONER1 and HARNESS ASSY TONER2
240 M-122 Connects SENSOR NO PAPER and HARNESS ASSY TRAY1
241 O-126 Connects SENSOR REGI and HARNESS ASSY TRAY1
242 Q-126 Connects CLUTCH ASSY PH and HARNESS ASSY TRAY1
243 P-126 Connects CLUTCH REGI and HARNESS ASSY TRAY1
244 M-124 Connects FAN MAIN and HARNESS ASSY TRAY1
245 M-125 Connects HARNESS ASSY TRAY1 and HARNESS ASSY CHUTE
246 M-123 Connects SENSOR NO PAPER and HARNESS ASSY TRAY2
247 Q-126 Connects CLUTCH ASSY PH and HARNESS ASSY TRAY2
248 M-126 Connects HARNESS ASSY TRAY2 and HARNESS ASSY CHUTE
260 N-126 Connects SENSOR LOW PAPER and HARNESS ASSY LOW PAPER SNR
270 T-119 Connects FAN SUB and HARNESS ASSY LVPS
271 U-120 Connects HARNESS ASSY LVPS and MAIN MOTOR
290 M-120 Connects SENSOR FULL STACK and HARNESS ASSY EXIT SNR1
291 M-120 Connects SENSOR FACE UP OPEN and HARNESS ASSY EXIT SNR1
310 M-122 Connects EP CARTRIGE and GUIDE ASSY CRU
480 W-125 Connects HARNESS ASSY 100V and POWER SWITCH
1821 A-109 Connects GUIDE TRAY L ASSY and HARNESS ASSY LVPS
2083 H-111 Connects HARNESS ASSY FDR1 and HARNESS ASSYFDR2
2750 S-126 Connects HARNESS ASSY LVPS and HARNESS ASSY DUP
3070 M-121 Connects HARNESS ASSY OCT1 and HARNESS ASSY OCT2
4647 T-126 Connects HARNESS ASSY FUSER and FUSER ASSY
P/J Coordinates Remarks
