5.5 Installation Procedures
5.5.1 Installing laser printer
For details, refer to the Instruction Manual supplied with the main unit.
When holding up the later printer, be sure to grasp the handles with both hands.
Grasping a part other than the handles result in fall or damage of the laser printer.
When holding up the later printer, bend your knees thoroughly to prevent lower
back strain.
The protection sheets and the fixing materials, which are removed before the
installation, are re-used when the later printer is moved to another place. Be sure to
keep them.
1) Unpack the laser printer, and place it in an installation location after removing
cushioning materials.
2) Confirm the attachments.
3) Peel off fixing tapes applied to the later printer.
4) Unpack the EP CARTRIDGE, then be sure to shake it seven to eight times holding
both sides.
When removing the toner seal, draw it out straight and horizontally. After
removal, be careful not to shake or give a shock to the EP CARTRIDGE.
5) Open the COVER OPEN, and install the EP CARTRIDGE.
6) Close the COVER OPEN.
7) Draw the paper tray, and press down the PLATE ASSY BTM to lock.
8) Place papers into the paper tray.
When placing papers into the paper tray, be careful for the followings:
- Align four corners of papers to place.
- Adjust the paper guide to the paper size.
- Do not place papers over the capacity or over the upper-limit line of the paper
tray.
9) Push the paper tray into the laser printer to install.
10) Connect the power cord.
11) Turn on the power switch of the laser printer.
12) Try some test printings with each paper-feed trays to confirm that there is no
problem.
