1 – 114
Chapter 1 Troubleshooting
7
Checking the image development process
Operate Test Print, and turn off the power of the printer
while printing.
Remove the EP CARTRIDGE with care, and check the
toner image formed on the drum, right before the tran-
scribe part (BTR).
Is the image on the drum completely formed?
Is the area clear and black, and easily read?
Go to step 8.
Go to FIP1.41
HVPS/MCU.
8
Checking the image transcribe process
Check the toner image formed on the drum, right after
the transcribe part (BTR).
Is the toner image on the drum completely transcribed
on the paper?
Go to step [ESS
and possible
causes].
Go to FIP1.41
HVPS/MCU.
Step Check Yes No
To Next Page
